| Specificații | |
| Altele | Bluetooth 5.3 Wi-Fi 7 (802.11be) |
| Dimensiuni (L x W) (cm) | 30.5 x 24.4 cm |
| Tehnologii suportate | Q-Flash Q-Flash Plus GIGABYTE Control Center (GCC) Smart Fan 6 |
| BIOS & memorie BIOS | AMI UEFI BIOS 1 x 256 Mbit flash |
| Sloturi speciale | 5 x M.2 |
| Conectivitate | 2 x USB 2.0 1 x RJ-45 1 x HDMI 2 x Audio Jacks 1 x optical S/PDIF Out 2 x SMA Antena Connectors (2T2R) 4 x USB 3.2 gen 1 2 x USB 3.2 Gen 2 1 x USB 3.2 Gen 2x2 20Gbps Type-C 1 x DisplayPort In Port |
| Sloturi PCI-E x16 | 3 |
| Rata de transfer SATA | 6000 MB/s |
| Conector sursa (pini) | 1 x 24 pin ATX 2 x 8 pin ATX 12V |
| Interfata Serial ATA | 4 x SATA III |
| LAN integrat | Realtek 5GbE LAN chip (5 Gbps/2.5 Gbps/1 Gbps/100 Mbps) |
| Audio integrat | Realtek ALC1220-VB codec |
| Slot PCI | PCI-Express 5.0 |
| Frecventa memorie (MHz) | 8266(O.C) / 8200(O.C) / 8000(O.C) / 7950(O.C) / 7900(O.C) / 7800(O.C) / 7600(O.C.) / 7400(O.C.) / 7200(O.C.) / 7000(O.C.) / 6800(O.C.) / 6600(O.C.) / 6400(O.C.) / 6200(O.C.) / 6000(O.C.) / 5800(O.C.) / 5600(O.C.) / 5400(O.C.) / 5200(O.C.) / 4800 / 4000 |
| Suport Dualchannel | Da |
| Sloturi memorie | 4 |
| Capacitate maxima memorie RAM | 192 GB |
| Tip memorie | DDR5 |
| CPU Socket | LGA 1700 |
| Chipset | Intel Z790 |
| Procesoare suportate | Intel Core din generatia 14, 13 si 12, Intel Pentium Gold, Celeron Processor |
| Format | ATX |
| Brand | Gigabyte |
